HTP20
Brentwood's HTP20 Cross-Fluted Trickle Fill is designed for use in applications where the circulating water has high levels of solids, such as in river or seawater applications, as well as waters with high-scale potential. It also performs well in towers that experience high sand and silica levels.
HTP20 balances thermal efficiency and fouling resistance in these applications by generating thin films of trickling water to enable cooling. It is a compact and low-fouling fill that features better performance than vertical-fluted film fills. Additionally, HTP20 features a patent-pending alternating tip that allows for proper drainage and limits bridging at pack transitions.
Benefits
Advanced flute geometry allows for trickling of water along structural members, increasing thermal performance.
Patent-pending alternating tip design reduces pressure drop and fouling between packs.
Made from UV-protected polypropylene copolymer and available in a fire-retardant formulation.
Navigate Within Trickle Fills
Fouling Resistant
As an alternative to film fills, HTP20 balances high efficiency with fouling resistance.
Open Design
Brentwood’s HTP20 features an open design that is ideal for applications with high levels of suspended solids.
Trickle Fill Specifications
English
Metric
| Product | Pack Sizes Standard D/W/L inches | Maximum Span inches | Sheet Size inches | Sheets Per Skid | Skid Dimensions L/W/H inches | Skid Weight (approx.) lbs |
|---|---|---|---|---|---|---|
| HTP20 | D: 17.72 W: 23.62 L: 35.83, 71.66 | 24 | 17.72 | 760 | 77.5 x 37 x 48 | 375 |
| NET 150 | D: 17.72 W: 11.85 L: 35.75 | 24 | 17.72 | 1701 | 53.9 x 36.2 x 96.1 | 891 |
| Product | Pack Sizes Standard D/W/L mm | Maximum Span mm | Sheet Size mm | Sheets Per Skid | Skid Dimensions L/W/H mm | Skid Weight (approx.) kg |
|---|---|---|---|---|---|---|
| HTP20 | D: 450 W: 600 L: 910, 1820 | 610 | 450 | 760 | 1969 x 940 x 1219 | 170 |
| NET 150 | D: 450 W: 301 L: 908 | 610 | 450 | 1701 | 1370 x 920 x 2440 | 404 |
